Projector Series

VIGCE+video projection wick+JYS

Video projection wick
Luminance video corwick
Film projector's wick
Liquid crystal projector
Product description: Economy LCD/DLP Projector Lamp(Wick/Burner), Video projection lamp wick has the advantages of small volume, high luminous efficiency, long service life, good starting performance, the second generatio
INQUIRY

巨源+视频投影灯芯+JYS

[product name] video projection wick
[product model] JYS
[Keywords] video projection wick, luminance video corwick, liquid crystal projector wick, film projector's Corp, high brightness contrast wick, high clarity projector lamp
Projection lamp light source
Metal halide discharge lamp core
[product characteristics]
1., small volume, high luminous efficiency, long service life and good startup performance; the 2. second generation high brightness video wick has advanced design of bubble and no drainage holes, making the series meet or surpass similar foreign high-end wicks in life, brightness, clarity and lightness. 3. wick with high purity quartz production, high pressure resistance, can withstand 200 standard atmospheric pressure, the equivalent of 3 gas tank or 2 oxygen pressure; 4. projection lamp wick consists of a spherical shell and special gas and electrode composition, manufacturing process, high temperature and high pressure; 5. good optical performance, long service life right, power; 6. with high reflective properties as the lamp Reflector, and light emission is good, high mechanical strength and good explosion-proof performance;
Film projector and liquid crystal projector
[comprehensive introduction]
The video projection wick has the advantages of small volume, high luminous efficiency, long service life, good starting performance and so on. It is generally used in film projector and liquid crystal projector. The second generation of high brightness video wick developed by giant source has been listed on the market. The lamp wick has advanced design of bubble and no drainage holes, making the series meet or surpass similar foreign high-end wicks in life, brightness, clarity and lightness.
[instructions]
Use the projector to ensure that the external environment of the projector is beneficial to heat dissipation. In use, there is no cover on the projector. Keep the electricity to cool the bulb for a period of time after use.
The projector opens the machine for a long time. After a long time, the manufacturer is invited to clean up the dust regularly to ensure heat dissipation and stability.
Do not buy low price, unguaranteed products. Don't take down the projector at random. The installation not in the lampshade, lamp cup, especially fingerprint left on the wick, fingerprint containing grease, will cause thermal expansion caused by uneven explosion.
[product photo]
[video data]
Universal projection light core, fine point projection light core, gold halogen type projection lamp core
[specification parameter]

灯泡型号 Lamp Type	功率 Watts w	工作电压 Operating Voltage V	工作电流 Current A	光通量 Lumens lm	色温 Color Temp K	光中心高度 Light Center Length	电弧长度 Effective Arc Length L mm	泡壳直径 Bulb Diam D mm	寿命 Average Life h
JYs120/D.C	120	75	1.5	7200	7800	37	2.4	11	2000
JYs120/A.C	120	75	1.5	7200	7800	37	2.4	11	2000
JYs150/D.C	150	75	2	9000	7500	39	2.5	12	2000
JYs150/A.C	150	75	2	9000	7500	37	2.5	12	2000
JYs180/D.C	180	75	2.3	11000	7600	40	2.6	13	2000
JYs180/A.C	180	75	2.3	11000	7600	37	2.6	13	2000
JYs200/D.C	200	75	2.6	12000	7400	37	2.7	14	2000
JYs200/A.C	200	75	2.6	12000	7400	40	2.7	14	2000
JYs250/D.C	250	60	4	15000	7400	37	2.8	15	2000
JYs250/A.C	250	60	4	15000	7400	41	2.8	15	2000
JYs280/D.C	280	60	4.5	16800	7500	37	2.9	16	2000
JYs280/A.C	280	60	4.5	16800	7500	41	2.9	16	2000
JYs350/D.C	350	60	5.8	21000	7400	41	3.0	17	2000
JYs400/D.C	400	50	8	23000	7000	41	3.5	18	2000
